PDB-code
| Kinase structure | |
| Kinase: | ILK |
| Family: | MLK |
| Group: | TKL |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2041 |
| PDB: | 6MIB |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2018-11-07 |
| PubMed: | 30367047 |
| Chain: | A |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 55.3° (17.3Å) |
| G-rich loop rotation: | 41.8° |
| Quality Score: | 7.6 |
| Resolution: | 1.8 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I3 I6 I8 I10 I11 | Ligand No No No No No | Protein Yes No Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | TKLNENHSGELWKIVVKVLDFNEECPRLRIFSPNVLPVLGATLITHWMPYGSLYNVLHEHTLEPLIPRHALNSRSVMIISMADVK |
| Sequence structure: | TKLNENHSGEWWKIVVKVLDFNEECPRLRIFSPNVLPVLGATLITHWMPYGSLYNVLHEHTLEPLIPRHALNSRSVMIISMADVK |
