PDB-code
| Kinase structure | |
| Kinase: | CDK2 |
| Family: | CDK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1973 |
| PDB: | 6Q49 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2019-03-20 |
| PubMed: | 30860382 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 6Q49 | |||||
| 6Q49 | Alternative model: | B | Chain: | A | |
| 6Q49 | Alternative model: | C | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 49.3° (14.1Å) |
| G-rich loop rotation: | 63.9° |
| Quality Score: | 8 |
| Resolution: | 1 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I4 I5 I6 | Ligand No No No No | Protein No No No Yes | ||
| Allosteric Ligand | |
| Allosteric ligand: | HGQ |
 | |
| Pocket alignment | |
| Uniprot sequence: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH-QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
| Sequence structure: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH_QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
