PDB-code
| Kinase structure | |
| Kinase: | CDK2 |
| Family: | CDK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1973 |
| PDB: | 6Q4K |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2019-03-20 |
| PubMed: | 30860382 |
| Chain: | A |
| (Alternate) Model: | C |
| More entries for 6Q4K | |||||
| 6Q4K | Alternative model: | A | Chain: | A | |
| 6Q4K | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 51.9° (14.7Å) |
| G-rich loop rotation: | 69° |
| Quality Score: | 7.2 |
| Resolution: | 1.06 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I3 I4 I5 I6 I7 | Ligand No No No No No No | Protein No No No Yes Yes Yes | ||
| Allosteric Ligand | |
| Allosteric ligand: | HHW |
 | |
| Pocket alignment | |
| Uniprot sequence: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH-QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
| Sequence structure: | EKIGEGTYGVVYKVA_KKITAIREISLLKELNPNIVKLLDVYLVFEFLH_QDLKKF_DAFCHSHRVLHRDLKPQNLLILADFGLA |
