PDB-code
| Kinase structure | |
| Kinase: | EPHA2 (EphA2) |
| Family: | Eph |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1822 |
| PDB: | 6HEX |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2019-08-28 |
| Chain: | A |
| (Alternate) Model: | C |
| More entries for 6HEX | |||||
| 6HEX | Alternative model: | A | Chain: | A | |
| 6HEX | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | out |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 68.2° (20.4Å) |
| G-rich loop rotation: | 82.9° |
| Quality Score: | 6.8 |
| Resolution: | 1.41 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I4 I7 | Ligand No No No | Protein Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | KVIGAGEFGEVYKVAIKTLDFLGEAGIMGQFSHNIIRLEGVMIITEYMENGALDKFLREYLANMNYVHRDLAARNILVVSDFGLS |
| Sequence structure: | KVIGAGEFGEVYKVAIKTLDFLGEAGIMGQFSHNI_RLEGVMIITEYMENGALDKFLREYLANMNYVHRDLAARNILVVSDFGL_ |
