PDB-code
| Kinase structure | |
| Kinase: | NEK1 |
| Family: | NEK |
| Group: | Other |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2114 |
| PDB: | 4APC |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2012-04-25 |
| PubMed: | 28710492 |
| Chain: | B |
| (Alternate) Model: | A |
| More entries for 4APC | |||||
| 4APC | Alternative model: | A | Chain: | A | |
| 4APC | Alternative model: | B | Chain: | A | |
| 4APC | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 6.7 |
| Resolution: | 2.1 Å |
| Missing Residues: | 5 |
| Missing Atoms: | 13 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I5 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | QKIGEGSFGKAILYVIKEIESRREVAVLANMKPNIVQYRESYIVMDYCEGGDLFKRINAHVHDRKILHRDIKSQNIFLLGDFGIA |
| Sequence structure: | QKIG_____KAILYVIKEIESRREVAVLANMKPNIVQYRESYIVMDYCEGGDLFKRINAHVHDRKILHRDIKSQNIFLLGDFGIA |
