| Kinase structure | |
| Kinase: | PRKAA1 (AMPKa1) |
| Family: | CAMKL |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1541 |
| PDB: | 4RED |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2014-12-10 |
| PubMed: | 25412657 |
| Chain: | A |
| More entries for 4RED | |||
| 4RED | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 71.3° (21.6Å) |
| G-rich loop rotation: | 66.8° |
| Quality Score: | 7.6 |
| Resolution: | 2.95 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | DTLGVGTFGKVKVVAVKILKIRREIQNLKLFRPHIIKLYQVFMVMEYVSGGELFDYICKYCHRHMVVHRDLKPENVLLIADFGLS |
| Sequence structure: | DTLGVGTFGKVKVVAVKILKIRREIQNLKLFRPHIIKLYQVFMVMEYVSGGELFDYICKYCHRHMVVHRDLKPENVLLIADFGLS |
