PDB-code
| Kinase structure | |
| Kinase: | MLKL |
| Family: | TKL-Unique |
| Group: | TKL |
| Species: | HUMAN |
| PDB: | 6O5Z |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2020-09-15 |
| PubMed: | 32902249 |
| Chain: | A |
| More entries for 6O5Z | |||
| 6O5Z | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 58.5° (18.2Å) |
| G-rich loop rotation: | 48.1° |
| Quality Score: | 8 |
| Resolution: | 2.285 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster O2 | Ligand No | Protein No | ||
| Pocket alignment | |
| Uniprot sequence: | ILLRENEVSTLYKVAIKVFTFNKEIKTMKKFEPNILRIFGISIVMEYCELGTLRELLDRHHSEAPELHGKIRSSNFLVLAGFELR |
| Sequence structure: | ILLRENEVSTLYKVAIKVFTFNKEIKTMKKFEPNILRIFGISIVMEYCELGTLRELLDRHHSEAPELHGKIRSSNFLVLAGFELR |
