PDB-code
| Kinase structure | |
| Kinase: | MAPK12 (p38g) |
| Family: | MAPK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1501 |
| PDB: | 7CGA |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2021-06-30 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 54.4° (15.6Å) |
| G-rich loop rotation: | 59.8° |
| Quality Score: | 8 |
| Resolution: | 3.15 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I5 I6 I10 | Ligand No No No No | Protein Yes Yes No Yes | ||
| Pocket alignment | |
| Uniprot sequence: | QPVGSGAYGAVCSVAIKKLRAYRELRLLKHMRENVIGLLDVYLVMPFMG-TDLGKLMKHYIHAAGIIHRDLKPGNLAVILDFGLA |
| Sequence structure: | QPVGSGAYGAVCSVAIKKLRAYRELRLLKHMRENVIGLLDVYLVMPFMG_TDLGKLMKHYIHAAGIIHRDLKPGNLAVILDFGLA |
