PDB-code
| Kinase structure | |
| Kinase: | PTK2 (FAK) |
| Family: | FAK |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2180 |
| PDB: | 7PI4 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2021-09-29 |
| PubMed: | 34416073 |
| Chain: | D |
| (Alternate) Model: | B |
| More entries for 7PI4 | |||||
| 7PI4 | Alternative model: | A | Chain: | D | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 65.9° (19.5Å) |
| G-rich loop rotation: | 86.8° |
| Quality Score: | 8 |
| Resolution: | 2.24 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I3 | Ligand No No | Protein Yes No | ||
| Pocket alignment | |
| Uniprot sequence: | RCIGEGQFGDVHQVAIKTCKFLQEALTMRQFDPHIVKLIGVWIIMELCTLGELRSFLQVYLESKRFVHRDIAARNVLVLGDFGLS |
| Sequence structure: | RCIGEGQFGDVHQVAIKTCKFLQEALTMRQFDPHIVKLIGVWIIMELCTLGELRSFLQVYLESKRFVHRDIAARNVLVLGDFGLS |
