PDB-code
| Kinase structure | |
| Kinase: | EGFR |
| Family: | EGFR |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1797 |
| PDB: | 7TVD |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2022-02-16 |
| PubMed: | 36357385 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 66.4° (20.4Å) |
| G-rich loop rotation: | 35.7° |
| Quality Score: | 7.6 |
| Resolution: | 2.96 Å |
| Missing Residues: | 1 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | KVLGSGAFGTVYKVAIKELEILDEAYVMASVDPHVCRLLGIQLITQLMPFGCLLDYVREYLEDRRLVHRDLAARNVLVITDFGLA |
| Sequence structure: | KVLGSGAFGTVYKVAIKE_EILDEAYVMASVDPHVCRLLGIQLITQLMPFGCLLDYVREYLEDRRLVHRDLAARNVLVITDFGLA |
