PDB-code
| Kinase structure | |
| Kinase: | INSRR (IRR) |
| Family: | InsR |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1802 |
| PDB: | 7TYK |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2023-02-15 |
| PubMed: | 37055497 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 107.3° (91Å) |
| G-rich loop rotation: | 138.9° |
| Quality Score: | 3.6 |
| Resolution: | 3.5 Å |
| Missing Residues: | 1 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | RELGQGSFGMVYEVALKTVEFLKEASVMKAFK-HVVRLLGVLVIMELMTRGDLKSHLRSYLAANKFVHRDLAARNCMVIGDFGMT |
| Sequence structure: | VGAGGHTYRVACRHLTSWRE_SIHQSCQSFTGLQLVVELNRGNLQLQHYLHGQNEINRDLRVSNVLLGTL |
