PDB-code
| Kinase structure | |
| Kinase: | PAK5 |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2138 |
| PDB: | 8C12 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2023-10-25 |
| PubMed: | 37776520 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 8C12 | |||||
| 8C12 | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 57.7° (17.4Å) |
| G-rich loop rotation: | 53° |
| Quality Score: | 8 |
| Resolution: | 1.549 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I2 I5 I8 I11 | Ligand No No No No No | Protein Yes No Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | IKIGEGSTGIVCIVAVKKMLLFNEVVIMRDYHDNVVDMYSSWVVMEFLEGGALTDIVTHYLHNQGVIHRDIKSDSILLLSDFGFC |
| Sequence structure: | IKIGEGSTGIVCIVAVKKMLLFNEVVIMRDYHDNVVDMYSSWVVMEFLEGGALTDIVTHYLHNQGVIHRDIKSDSILLLSDFGFC |
