PDB-code
| Kinase structure | |
| Kinase: | PDGFRA (PDGFRa) |
| Family: | PDGFR |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1803 |
| PDB: | 8PQJ |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2023-12-27 |
| PubMed: | 38167404 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 8PQJ | |||||
| 8PQJ | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | out |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 62.5° (19Å) |
| G-rich loop rotation: | 46.5° |
| Quality Score: | 7.2 |
| Resolution: | 1.82 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I5 I6 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | RVLGSGAFGKVVEVAVKMLALMSELKIMTHLGLNIVNLLGAYIITEYCFYGDLVNYLHKFLASKNCVHRDLAARNVLLICDFGLA |
| Sequence structure: | RVLGSGAFGKVVEVAVKMLALMSELKIMTHLGLNIVNLLGAYIITEYCFYGDLVNYLHKFLASKNCVHRDLAARNVLLICDFGLA |
