PDB-code
| Kinase structure | |
| Kinase: | LRRK2 |
| Family: | LRRK |
| Group: | TKL |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2059 |
| PDB: | 8U8B |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2024-01-31 |
| PubMed: | 38263358 |
| Chain: | A |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 20.9° (54.3Å) |
| G-rich loop rotation: | 42.2° |
| Quality Score: | 5.2 |
| Resolution: | 3.7 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 8 |
| Allosteric Ligand | |
| Allosteric ligand: | 919 |
 | |
| Pocket alignment | |
| Uniprot sequence: | ADHGDGSFGSVYRVAVKIFLLRQELVVLCHLHPSLISLLAAMLVMELASKGSLDRLLQQYLHSAMIIYRDLKPHNVLLIADYGIA |
| Sequence structure: | LIGKGDSARLDYLVVGRLLQLVREP |
