PDB-code
| Kinase structure | |
| Kinase: | WNK1 (Wnk1) |
| Family: | WNK |
| Group: | Other |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2280 |
| PDB: | 4PWN |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2014-05-28 |
| PubMed: | 24803536 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 60.4° (17.2Å) |
| G-rich loop rotation: | 14.1° |
| Quality Score: | 7.6 |
| Resolution: | 1.84 Å |
| Missing Residues: | 1 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I3 I4 I5 | Ligand No No No | Protein Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | IEIGRGSFKTVYKVAWCELRFKEEAEMLKGLQPNIVRFYDSVLVTELMTSGTLKTYLKRHTRTPPIIHRDLKCDNIFIIGDLGLA |
| Sequence structure: | IEIGRGSFKTVYKVAWCEL_FKEEAEMLKGLQPNIVRFYDSVLVTELMTSGTLKTYLKRHTRTPPIIHRDLKCDNIFIIGDLGLA |
