PDB-code
| Kinase structure | |
| Kinase: | MAPK10 (JNK3) |
| Family: | MAPK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1498 |
| PDB: | 4H39 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2012-11-21 |
| PubMed: | 23142346 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 4H39 | |||||
| 4H39 | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 68.5° (20.2Å) |
| G-rich loop rotation: | 48.6° |
| Quality Score: | 7.9 |
| Resolution: | 1.99 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 13 |
| Pocket alignment | |
| Uniprot sequence: | KPIGSGAQGIVCAVAIKKLRAYRELVLMKCVNKNIISLLNVYLVMELMD-ANLCQVIQMHLHSAGIIHRDLKPSNIVVILDFGLA |
| Sequence structure: | KPIGSGAQGIVCAVAIKKLRAYRELVLMKCVNKNIISLLNVYLVMELMD_ANLCQVIQMHLHSAGIIHRDLKPSNIVVILDFG__ |
