PDB-code
| Kinase structure | |
| Kinase: | CDK2 |
| Family: | CDK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1973 |
| PDB: | 1URC |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2003-10-31 |
| PubMed: | 15455144 |
| Chain: | C |
| (Alternate) Model: | B |
| More entries for 1URC | |||||
| 1URC | Alternative model: | A | Chain: | A | |
| 1URC | Alternative model: | A | Chain: | C | |
| 1URC | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 51.3° (15.1Å) |
| G-rich loop rotation: | 77.2° |
| Quality Score: | 8 |
| Resolution: | 2.6 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I7 I8 I11 | Ligand No No No No | Protein Yes No No No | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH-QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
| Sequence structure: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH_QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
