PDB-code
| Kinase structure | |
| Kinase: | CDK2 |
| Family: | CDK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1973 |
| PDB: | 1F5Q |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2000-12-27 |
| PubMed: | 10856233 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 1F5Q | |||||
| 1F5Q | Alternative model: | A | Chain: | C | |
| 1F5Q | Alternative model: | B | Chain: | A | |
| 1F5Q | Alternative model: | B | Chain: | C | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 66.9° (19.2Å) |
| G-rich loop rotation: | 62.6° |
| Quality Score: | 8.5 |
| Resolution: | 2.5 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 7 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I4 I5 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH-QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
| Sequence structure: | EK__EGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH_QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
