PDB-code
| Kinase structure | |
| Kinase: | CDK2 |
| Family: | CDK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1973 |
| PDB: | 4EK3 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2013-05-01 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 4EK3 | |||||
| 4EK3 | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 51.2° (14.7Å) |
| G-rich loop rotation: | 68.1° |
| Quality Score: | 8 |
| Resolution: | 1.34 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I3 I4 I5 I6 | Ligand No No No No No | Protein No Yes No Yes No | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH-QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
| Sequence structure: | EKIGEGTYGVVYKVALKKITAIREISLLKELNPNIVKLLDVYLVFEFLH_QDLKKFMDAFCHSHRVLHRDLKPQNLLILADFGLA |
