PDB-code
| Kinase structure | |
| Kinase: | PLK1 |
| Family: | PLK |
| Group: | Other |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2168 |
| PDB: | 2V5Q |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2008-04-01 |
| PubMed: | 18391401 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 2V5Q | |||||
| 2V5Q | Alternative model: | A | Chain: | B | |
| 2V5Q | Alternative model: | B | Chain: | A | |
| 2V5Q | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 55.9° (16Å) |
| G-rich loop rotation: | 59.9° |
| Quality Score: | 8 |
| Resolution: | 2.3 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I2 I4 I5 I7 | Ligand No No No No No | Protein Yes Yes Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | RFLGKGGFAKCFEFAGKIVKMSMEISIHRSLAQHVVGFHGFFVVLELCRRRSLLELHKRYLHRNRVIHRDLKLGNLFLIGDFGLA |
| Sequence structure: | RFLGKGGFAKCFEFAGKIVKMSMEISIHRSLAQHVVGFHGFFVVLELCRRRSLLELHKRYLHRNRVIHRDLKLGNLFLIGDFGLA |
