PDB-code
| Kinase structure | |
| Kinase: | DAPK1 |
| Family: | DAPK |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2002 |
| PDB: | 4PF4 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2014-05-14 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 4PF4 | |||||
| 4PF4 | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 54° (16Å) |
| G-rich loop rotation: | 42.8° |
| Quality Score: | 9.6 |
| Resolution: | 1.13 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 4 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I3 I4 I5 I7 | Ligand No No No No No | Protein Yes Yes Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EELGSGQFAVVKKYAAKFIDIEREVSILKEIQPNVITLHEVILILELVAGGELFDFLAEYLHSLQIAHFDLKPENIMLIIDFGLA |
| Sequence structure: | EELGSGQFAVVKKYAAKFIDIEREVSILKEIQPNVITLHEVILILELVAGGELFDFLAEYLHSLQIAHFDLKPENIMLIIDFGLA |
