| Kinase structure | |
| Kinase: | Prkaca (PKACa) |
| Family: | PKA |
| Group: | AGC |
| Species: | MOUSE |
| PDB: | 1JBP |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2001-06-27 |
| PubMed: | 8003955 |
| Chain: | E |
| Orthosteric ligand: | ADP |
 | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 49.5° (15.1Å) |
| G-rich loop rotation: | 66.9° |
| Quality Score: | 9.1 |
| Resolution: | 2.2 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 9 |
| Ligand binding mode | ||||
| Pockets | Subpockets | Waters | ||
| front | FP-II | Cluster I1 I5 | Ligand No Yes | Protein Yes Yes |
| Pocket alignment | |
| Uniprot sequence: | KTLGTGSFGRVMLYAMKILHTLNEKRILQAVNPFLVKLEFSYMVMEYVAGGEMFSHLRRYLHSLDLIYRDLKPENLLIVTDFGFA |
| Sequence structure: | KTLGTGSFGRVMLYAMKILHTLNEKRILQAVNPFLVKLEFSYMVMEYVAGGEMFSHLRRYLHSLDLIYRDLKPENLLIVTDFGFA |
| Ligand affinity | |
| ChEMBL ID: | CHEMBL14830 |
| Bioaffinities: | 2 records for 1 kinase |
| Species | Kinase (ChEMBL naming) | Median | Min | Max | Type | Records |
|---|---|---|---|---|---|---|
| Homo sapiens | Mitogen-activated protein kinase kinase kinase 7 | 4.2 | 4.2 | 5.4 | pKd | 2 |
Kinase-ligand interaction pattern
• Hydrophobic • Aromatic face-to-face • Aromatic face-to-edge • H-bond donor • H-bond acceptor • Ionic positive • Ionic negative
| I | g.l | II | III | αC | |||||||||||||||
| 1 K 47 | 2 T 48 | 3 L 49 | 4 G 50 | 5 T 51 | 6 G 52 | 7 S 53 | 8 F 54 | 9 G 55 | 10 R 56 | 11 V 57 | 12 M 58 | 13 L 59 | 14 Y 69 | 15 A 70 | 16 M 71 | 17 K 72 | 18 I 73 | 19 L 74 | 20 H 87 |
| • | • | • | • | • | • | • | • | ||||||||||||
| αC | b.l | IV | |||||||||||||||||
| 21 T 88 | 22 L 89 | 23 N 90 | 24 E 91 | 25 K 92 | 26 R 93 | 27 I 94 | 28 L 95 | 29 Q 96 | 30 A 97 | 31 V 98 | 32 N 99 | 33 P 101 | 34 F 102 | 35 L 103 | 36 V 104 | 37 K 105 | 38 L 106 | 39 E 107 | 40 F 108 |
| IV | V | GK | hinge | linker | αD | αE | |||||||||||||
| 41 S 109 | 42 Y 117 | 43 M 118 | 44 V 119 | 45 M 120 | 46 E 121 | 47 Y 122 | 48 V 123 | 49 A 124 | 50 G 125 | 51 G 126 | 52 E 127 | 53 M 128 | 54 F 129 | 55 S 130 | 56 H 131 | 57 L 132 | 58 R 133 | 59 R 134 | 60 Y 156 |
| • | •• | •• | •• | ||||||||||||||||
| αE | VI | c.l | VII | VIII | x | ||||||||||||||
| 61 L 157 | 62 H 158 | 63 S 159 | 64 L 160 | 65 D 161 | 66 L 162 | 67 I 163 | 68 Y 164 | 69 R 165 | 70 D 166 | 71 L 167 | 72 K 168 | 73 P 169 | 74 E 170 | 75 N 171 | 76 L 172 | 77 L 173 | 78 I 174 | 79 V 182 | 80 T 183 |
| • | •• | ||||||||||||||||||
| DFG | a.l | ||||||||||||||||||
| 81 D 184 | 82 F 185 | 83 G 186 | 84 F 187 | 85 A 188 | |||||||||||||||
Interaction pattern search
Search KLIFS for kinase-ligand complexes with similar interaction patterns:
