PDB-code
| Kinase structure | |
| Kinase: | MAP4K4 (HGK) |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2088 |
| PDB: | 4U3Z |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2016-01-06 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 4U3Z | |||||
| 4U3Z | Alternative model: | A | Chain: | B | |
| 4U3Z | Alternative model: | B | Chain: | A | |
| 4U3Z | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 5.2 |
| Resolution: | 2.09 Å |
| Missing Residues: | 7 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I5 | Ligand No No | Protein No Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EVVGNGTYGQVYKAAIKVMEIKLEINMLKKYSRNIATYYGAWLVMEFCGAGSITDLVKNHLHIHHVIHRDIKGQNVLLLVDFGVS |
| Sequence structure: | EVV_______VYKAAIKVMEIKLEINMLKKYSRNIATYYGAWLVMEFCGAGSITDLVKNHLHIHHVIHRDIKGQNVLLLVDFGVS |
