PDB-code
| Kinase structure | |
| Kinase: | CSNK1D (CK1d) |
| Family: | CK1 |
| Group: | CK1 |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1997 |
| PDB: | 5IH4 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2016-04-13 |
| PubMed: | 27049670 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 5IH4 | |||||
| 5IH4 | Alternative model: | A | Chain: | A | |
| 5IH4 | Alternative model: | C | Chain: | A | |
| 5IH4 | Alternative model: | D | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 46.7° (14.7Å) |
| G-rich loop rotation: | 86.5° |
| Quality Score: | 8 |
| Resolution: | 1.9 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I8 I10 | Ligand No No No | Protein No Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | RKIGSGSFGDIYLVAIKLEQLHIESKIYKMMQVGIPTIRWCVMVMELLG-PSLEDLFNFYIHSKNFIHRDVKPDNFLMIIDFGLA |
| Sequence structure: | RKIGSGSFGDIYLVAIKLEQLHIESKIYKMMQVGIPTIRWCVMVMELLG_PSLEDLFNFYIHSKNFIHRDVKPDNFLMIIDFGLA |
