PDB-code
| Kinase structure | |
| Kinase: | EPHA2 (EphA2) |
| Family: | Eph |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1822 |
| PDB: | 5NK2 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2017-06-07 |
| PubMed: | 28544567 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 5NK2 | |||||
| 5NK2 | Alternative model: | A | Chain: | A | |
| 5NK2 | Alternative model: | C | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 67° (21Å) |
| G-rich loop rotation: | 55.4° |
| Quality Score: | 8 |
| Resolution: | 1.65 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I3 I10 | Ligand No No No | Protein Yes No Yes | ||
| Pocket alignment | |
| Uniprot sequence: | KVIGAGEFGEVYKVAIKTLDFLGEAGIMGQFSHNIIRLEGVMIITEYMENGALDKFLREYLANMNYVHRDLAARNILVVSDFGLS |
| Sequence structure: | KVIGAGEFGEVYKVAIKTLDFLGEAGIMGQFSHNIIRLEGVMIITEYMENGALDKFLREYLANMNYVHRDLAARNILVVSDFGLS |
