PDB-code
| Kinase structure | |
| Kinase: | WNK3 (Wnk3) |
| Family: | WNK |
| Group: | Other |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2282 |
| PDB: | 5O23 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2017-06-28 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 5O23 | |||||
| 5O23 | Alternative model: | A | Chain: | B | |
| 5O23 | Alternative model: | B | Chain: | A | |
| 5O23 | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 64.3° (17.7Å) |
| G-rich loop rotation: | 17.6° |
| Quality Score: | 9.6 |
| Resolution: | 2.25 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 4 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I6 | Ligand No | Protein Yes | ||
| Pocket alignment | |
| Uniprot sequence: | IELGRGAFKTVYKVAWCELRFKEEAEMLKGLQPNIVRFYDSVLVTELMTSGTLKTYLKRHTRTPPIIHRDLKCDNIFIIGDLGLA |
| Sequence structure: | IELGRGAFKTVYKVAWCELRFKEEAEMLKGLQPNIVRFYDSVLVTELMTSGTLKTYLKRHTRTPPIIHRDLKCDNIFIIGDLGLA |
