PDB-code
| Kinase structure | |
| Kinase: | EGFR |
| Family: | EGFR |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1797 |
| PDB: | 2RF9 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2007-12-04 |
| PubMed: | 18046415 |
| Chain: | A |
| More entries for 2RF9 | |||
| 2RF9 | Chain: | B | |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 48.6° (14.8Å) |
| G-rich loop rotation: | 43° |
| Quality Score: | 8 |
| Resolution: | 3.5 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 53 |
| Pocket alignment | |
| Uniprot sequence: | KVLGSGAFGTVYKVAIKELEILDEAYVMASVDPHVCRLLGIQLITQLMPFGCLLDYVREYLEDRRLVHRDLAARNVLVITDFGLA |
| Sequence structure: | KVLGSGAFGTVYKVAIKELEILDEAYVMASVDPHVCRLLGIQLITQLMPFGCLLDYVREYLEDRRLVHRDLAARNVLVITDFGLA |
