PDB-code
| Kinase structure | |
| Kinase: | PIK3CG (p110g) |
| Family: | PIK |
| Group: | Atypical |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2156 |
| PDB: | 3CSF |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2008-05-27 |
| PubMed: | 18484710 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 58.2° (17.8Å) |
| G-rich loop rotation: | 93.6° |
| Quality Score: | 7.2 |
| Resolution: | 2.8 Å |
| Missing Residues: | 1 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | CKVMASKKKPLWLIIFKHGDLRQDMLILQILRLCLLPYGCIIGMIEIVKATTIAKIQQSATFV--LGIGDRHNDNIMIHIDFGHI |
| Sequence structure: | CKVMASKKKPLWLIIFKHGDLRQDMLILQILRLCLLPYGCIIGMIEIVKATTIAKIQQSATFV__LGIGDRHNDNIMIHIDFGH_ |
