PDB-code
| Kinase structure | |
| Kinase: | EPHB4 (EphB4) |
| Family: | Eph |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1833 |
| PDB: | 6FNL |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2018-08-08 |
| PubMed: | 29928781 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 6FNL | |||||
| 6FNL | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 63.2° (18.9Å) |
| G-rich loop rotation: | 84.9° |
| Quality Score: | 7.2 |
| Resolution: | 1.27 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I5 I6 I7 I8 | Ligand No No No No No | Protein Yes Yes No No No | ||
| Pocket alignment | |
| Uniprot sequence: | EVIGAGEFGEVCRVAIKTLEFLSEASIMGQFEPNIIRLEGVMILTEFMENGALDSFLRLYLAEMSYVHRDLAARNILVVSDFGLS |
| Sequence structure: | EVIGAGEFGEVCRVAIKTLEFLSEASIMGQFEPNIIRLEGVMILTEFMENGALDSFLRLYLAEMSYVHRDLAARNILVVSDFG__ |
