PDB-code
| Kinase structure | |
| Kinase: | PRKG1 (PKG1) |
| Family: | PKG |
| Group: | AGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1492 |
| PDB: | 6BDL |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2018-10-24 |
| Chain: | B |
| (Alternate) Model: | A |
| More entries for 6BDL | |||||
| 6BDL | Alternative model: | A | Chain: | A | |
| 6BDL | Alternative model: | B | Chain: | A | |
| 6BDL | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 61.1° (18.7Å) |
| G-rich loop rotation: | 50.5° |
| Quality Score: | 9 |
| Resolution: | 1.96 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 10 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I11 | Ligand No | Protein Yes | ||
| Pocket alignment | |
| Uniprot sequence: | DTLGVGGFGRVELFAMKILHIRSEKQIMQGAHDFIVRLYRTYMLMEACLGGELWTILRDYLHSKGIIYRDLKPENLILLVDFGFA |
| Sequence structure: | DTLGVGGFGRVELFAMKILHIRSEKQIMQGAHDFIVRLYRTYMLMEACLGGELWTILRDYLHSKGIIYRDLKPENLILLVDFGFA |
