PDB-code
| Kinase structure | |
| Kinase: | MAP4K1 (HPK1) |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2085 |
| PDB: | 6CQE |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2018-12-19 |
| PubMed: | 30503777 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 6CQE | |||||
| 6CQE | Alternative model: | A | Chain: | A | |
| 6CQE | Alternative model: | A | Chain: | B | |
| 6CQE | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 6.4 |
| Resolution: | 1.89 Å |
| Missing Residues: | 4 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I3 I6 | Ligand No No | Protein Yes No | ||
| Pocket alignment | |
| Uniprot sequence: | QRLGGGTYGEVFKVALKMVTLQKEILILKTCRANIVAYHGSWICMEFCGAGSLQDIYQVYLHSQKKIHRDIKGANILILADFGIS |
| Sequence structure: | QRLG____GEVFKVALKMVTLQKEILILKTCRANIVAYHGSWICMEFCGAGSLQDIYQVYLHSQKKIHRDIKGANILILADFGIS |
