PDB-code
| Kinase structure | |
| Kinase: | CSF1R (FMS) |
| Family: | PDGFR |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1806 |
| PDB: | 2OGV |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2007-02-06 |
| PubMed: | 17292918 |
| Chain: | A |
| Structural information | |
| DFG conformation: | out |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 64° (19.2Å) |
| G-rich loop rotation: | 46.4° |
| Quality Score: | 7.4 |
| Resolution: | 2.7 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I5 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | KTLGAGAFGKVVEVAVKMLALMSELKIMSHLGENIVNLLGALVITEYCCYGDLLNFLRRFLASKNCIHRDVAARNVLLIGDFGLA |
| Sequence structure: | KTLGAGAFGKVVEVAVKMLALMSELKIMSHLGENIVNLLGALVITEYCCYGDLLNFLRRFLASKNCIHRDVAARNVLLIGDFGLA |
