PDB-code
| Kinase structure | |
| Kinase: | CAMK2A (CaMK2a) |
| Family: | CAMK2 |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1555 |
| PDB: | 6W4O |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2020-07-15 |
| PubMed: | 32694170 |
| Chain: | O |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 61.5° (18.8Å) |
| G-rich loop rotation: | 60.2° |
| Quality Score: | 7.2 |
| Resolution: | NMR |
| Missing Residues: | 2 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | EELGKGAFSVVRRYAAKIIKLEREARICRLLKPNIVRLHDSYLIFDLVTGGELFEDIVAHCHQMGVVHRDLKPENLLLLADFGLA |
| Sequence structure: | EELGKG__SVVRRYAAMIIKLEREARICRLLKPNIVRLHDSYLIFDLVTGGELFEDIVAHCHQMGVVHRNLKPENLLLLADFGLA |
