PDB-code
| Kinase structure | |
| Kinase: | MAPKAPK2 |
| Family: | MAPKAPK |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2094 |
| PDB: | 4TYH |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2015-07-22 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 4TYH | |||||
| 4TYH | Alternative model: | A | Chain: | A | |
| 4TYH | Alternative model: | A | Chain: | B | |
| 4TYH | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 62.3° (18Å) |
| G-rich loop rotation: | 73.2° |
| Quality Score: | 8 |
| Resolution: | 3 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | QVLGLGINGKVLQFALKMLKARREVELHWRASPHIVRIVDVLIVMECLDGGELFSRIQDYLHSINIAHRDVKPENLLYLTDFGFA |
| Sequence structure: | QVLGLGINGKVLQFALKMLKARREVELHWRASPHIVRIVDVLIVMECLDGGELFSRIQDYLHSINIAHRDVKPENLLYLTDFGFA |
