PDB-code
| Kinase structure | |
| Kinase: | MAPKAPK2 |
| Family: | MAPKAPK |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2094 |
| PDB: | 2ONL |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2007-02-06 |
| PubMed: | 17255097 |
| Chain: | D |
| More entries for 2ONL | |||
| 2ONL | Chain: | A | |
| 2ONL | Chain: | B | |
| 2ONL | Chain: | C | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 127.5° (33.8Å) |
| G-rich loop rotation: | 122.6° |
| Quality Score: | 6 |
| Resolution: | 4 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Pocket alignment | |
| Uniprot sequence: | QVLGLGINGKVLQFALKMLKARREVELHWRASPHIVRIVDVLIVMECLDGGELFSRIQDYLHSINIAHRDVKPENLLYLTDFGFA |
| Sequence structure: | QIKKNAIIDDVLQFALKMLKARREVELHWRASPHIVRIVDVLIVMECLDGGELFSRIQDYLHSINIAHRDVKPENLLYLTDFGFA |
