PDB-code
| Kinase structure | |
| Kinase: | PAK1 |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2133 |
| PDB: | 4O0R |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2014-02-12 |
| PubMed: | 24432870 |
| Chain: | B |
| More entries for 4O0R | |||
| 4O0R | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 69.4° (19.9Å) |
| G-rich loop rotation: | 52.1° |
| Quality Score: | 7.2 |
| Resolution: | 2.4 Å |
| Missing Residues: | 2 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I7 | Ligand No | Protein Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGQGASGTVYTVAIKQMLIINEILVMRENKPNIVNYLDSWVVMEYLAGGSLTDVVTEFLHSNQVIHRDIKSDNILLLTDFGFC |
| Sequence structure: | EKIGQGASGTVYTVAIKQMLIINEILVMRENKPNIVNYLDSWVVMEYLAGGSLTDVVTEFLHSNQVIHRNIKSDNILLLTDFG__ |
