PDB-code
| Kinase structure | |
| Kinase: | PRKG1 (PKG1) |
| Family: | PKG |
| Group: | AGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1492 |
| PDB: | 7T4V |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2023-06-14 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 7T4V | |||||
| 7T4V | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 58.8° (18.6Å) |
| G-rich loop rotation: | 53.3° |
| Quality Score: | 8 |
| Resolution: | 2.28 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Allosteric Ligand | |
| Allosteric ligand: | EXZ |
 | |
| Pocket alignment | |
| Uniprot sequence: | DTLGVGGFGRVELFAMKILHIRSEKQIMQGAHDFIVRLYRTYMLMEACLGGELWTILRDYLHSKGIIYRDLKPENLILLVDFGFA |
| Sequence structure: | DTLGVGGFGRVELFAMKILHIRSEKQIMQGAHDFIVRLYRTYMLMEACLGGELWTILRDYLHSKGIIYRDLKPENLILLVDFGFA |
