PDB-code
| Kinase structure | |
| Kinase: | CHEK1 (CHK1) |
| Family: | CAMKL |
| Group: | CAMK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1987 |
| PDB: | 3JVS |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2009-10-06 |
| PubMed: | 19743875 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 8.1 |
| Resolution: | 1.9 Å |
| Missing Residues: | 4 |
| Missing Atoms: | 3 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I4 I5 I6 I8 I11 | Ligand No No No No No No | Protein Yes Yes Yes No Yes Yes | ||
| Allosteric Ligand | |
| Allosteric ligand: | AGY |
 | |
| Pocket alignment | |
| Uniprot sequence: | QTLGEGAYGEVQLVAVKIVNIKKEICINKMLNENVVKFYGHYLFLEYCSGGELFDRIEPYLHGIGITHRDIKPENLLLISDFGLA |
| Sequence structure: | QTLGE____EVQLVAVKIVNIKKEICINKMLNENVVKFYGHYLFLEYCSGGELFDRIEPYLHGIGITHRDIKPENLLLISDFGLA |
