PDB-code
| Kinase structure | |
| Kinase: | PAK1 |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2133 |
| PDB: | 3Q4Z |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2011-12-21 |
| PubMed: | 22153498 |
| Chain: | B |
| (Alternate) Model: | B |
| More entries for 3Q4Z | |||||
| 3Q4Z | Alternative model: | A | Chain: | A | |
| 3Q4Z | Alternative model: | A | Chain: | B | |
| 3Q4Z | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 70.5° (19.9Å) |
| G-rich loop rotation: | 48.4° |
| Quality Score: | 6.8 |
| Resolution: | 1.89 Å |
| Missing Residues: | 3 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I6 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGQGASGTVYTVAIKQMLIINEILVMRENKPNIVNYLDSWVVMEYLAGGSLTDVVTEFLHSNQVIHRDIKSDNILLLTDFGFC |
| Sequence structure: | EKIGQGASGTVYTVAIRQMLIINEILVMRENKPNIVNYLDSWVVMEYLAGGSLTDVVTEFLHSNQVIHRNIKSDNILLLTDF___ |
