PDB-code
| Kinase structure | |
| Kinase: | PAK1 |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2133 |
| PDB: | 4ZLO |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2015-08-05 |
| PubMed: | 26191365 |
| Chain: | B |
| (Alternate) Model: | A |
| More entries for 4ZLO | |||||
| 4ZLO | Alternative model: | A | Chain: | A | |
| 4ZLO | Alternative model: | B | Chain: | A | |
| 4ZLO | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 5.6 |
| Resolution: | 2.5 Å |
| Missing Residues: | 6 |
| Missing Atoms: | 22 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I8 | Ligand No | Protein Yes | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGQGASGTVYTVAIKQMLIINEILVMRENKPNIVNYLDSWVVMEYLAGGSLTDVVTEFLHSNQVIHRDIKSDNILLLTDFGFC |
| Sequence structure: | EKIGQ_____VYTVAIKQMLIINEILVMRENKPNIVNYLDS_VVMEYLAGGSLTDVVTEFLHSNQVIHRDIKSDNILLLTDFGFC |
