PDB-code
| Kinase structure | |
| Kinase: | AKT2 |
| Family: | Akt |
| Group: | AGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1480 |
| PDB: | 1GZK |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2003-05-22 |
| PubMed: | 12086620 |
| Chain: | A |
| Structural information | |
| DFG conformation: | out |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 60.7° (18.2Å) |
| G-rich loop rotation: | 47.2° |
| Quality Score: | 5.6 |
| Resolution: | 2.3 Å |
| Missing Residues: | 3 |
| Missing Atoms: | 30 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I3 I5 I6 I7 | Ligand No No No No | Protein Yes Yes Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | KLLGKGTFGKVILYAMKILHTVTESRVLQNTRPFLTALKYACFVMEYANGGELFFHLSRYLHSRDVVYRDIKLENLMLITDFGLC |
| Sequence structure: | KLLGKGTFGKVILYAMKIL__VTESRVLQNTRPFLTALKYACFVMEYANGGELFFHLSRYLHSRDVVYRDIKLENLMLITDFGL_ |
