PDB-code
| Kinase structure | |
| Kinase: | AKT1 |
| Family: | Akt |
| Group: | AGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1479 |
| PDB: | 3O96 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2010-10-13 |
| PubMed: | 20886116 |
| Chain: | A |
| Structural information | |
| DFG conformation: | out |
| αC-helix conformation: | na |
| G-rich loop angle (distance): | 62.6° (19.1Å) |
| G-rich loop rotation: | 53.2° |
| Quality Score: | 5.2 |
| Resolution: | 2.7 Å |
| Missing Residues: | 5 |
| Missing Atoms: | 0 |
| Allosteric Ligand | |
| Allosteric ligand: | IQO |
 | |
| Pocket alignment | |
| Uniprot sequence: | KLLGKGTFGKVILYAMKILHTLTENRVLQNSRPFLTALKYSCFVMEYANGGELFFHLSRLHSEKNVVYRDLKLENLMLITDFGLC |
| Sequence structure: | KLLGKGTFGKVILYAMKIL_____NRVLQNSRPFLTALKYSCFVMEYANGGELFFHLSRLHSEKNVVYRDLKLENLMLITDFGLC |
