PDB-code
| Kinase structure | |
| Kinase: | MAPK8 (JNK1) |
| Family: | MAPK |
| Group: | CMGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1496 |
| PDB: | 1UKH |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2004-08-30 |
| PubMed: | 15141161 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 60.7° (17.8Å) |
| G-rich loop rotation: | 50.7° |
| Quality Score: | 7.6 |
| Resolution: | 2.35 Å |
| Missing Residues: | 1 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I8 I10 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | KPIGSGAQGIVCAVAIKKLRAYRELVLMKCVNKNIIGLLNVYIVMELMD-ANLCQVIQMHLHSAGIIHRDLKPSNIVVILDFGLA |
| Sequence structure: | KPIGSGAQGIVCAVAIKKLRAYRELVLMKCVNKNIIGLLNVYIVMELMD_ANLCQVIQMHLHSAGIIHRDLKPSNIVVILDFGL_ |
