PDB-code
| Kinase structure | |
| Kinase: | TTK |
| Family: | TTK |
| Group: | Other |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2264 |
| PDB: | 4C4E |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2013-12-04 |
| PubMed: | 24256217 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 4C4E | |||||
| 4C4E | Alternative model: | A | Chain: | A | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 60.1° (18.7Å) |
| G-rich loop rotation: | 55.6° |
| Quality Score: | 8.5 |
| Resolution: | 2.6 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 15 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 | Ligand No | Protein No | ||
| Pocket alignment | |
| Uniprot sequence: | KQIGSGGSSKVFQYAIKYVSYRNEIAYLNKLQDKIIRLYDYYMVMECGN-IDLNSWLKKTIHQHGIVHSDLKPANFLILIDFGIA |
| Sequence structure: | KQIGSGGSSKVFQYAIKYVSYRNEIAYLNKLQDKIIRLYDYYMVMECGN_IDLNSWLKKTIHQHGIVHSDLKPANFLILIDFGIA |
