PDB-code
| Kinase structure | |
| Kinase: | ALK |
| Family: | ALK |
| Group: | TK |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1839 |
| PDB: | 4FNX |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2012-08-29 |
| PubMed: | 22932897 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 5.6 |
| Resolution: | 1.7 Å |
| Missing Residues: | 6 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I2 I6 I9 | Ligand No No No No | Protein Yes No No No | ||
| Pocket alignment | |
| Uniprot sequence: | RGLGHGAFGEVYEVAVKTLDFLMEALIISKFNQNIVRCIGVFILLELMAGGDLKSFLREYLEENHFIHRDIAARNCLLIGDFGMA |
| Sequence structure: | RGL______EVYEVAVKTLDFLMEALIISKFNQNIVRCIGVFILLELMAGGDLKSFLREYLEENHFIHRDIAARNCLLIGDFGMA |
