PDB-code
| Kinase structure | |
| Kinase: | STK24 (MST3) |
| Family: | STE20 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2217 |
| PDB: | 3A7F |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2010-02-02 |
| PubMed: | 20124694 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 55.6° (15.7Å) |
| G-rich loop rotation: | 93.4° |
| Quality Score: | 8 |
| Resolution: | 1.55 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I2 I4 I5 I6 I7 | Ligand No No No No No | Protein Yes Yes Yes No No | ||
| Pocket alignment | |
| Uniprot sequence: | EKIGKGSFGEVFKVAIKIIDIQQEITVLSQCDPYVTKYYGSWIIMEYLGGGSALDLLEPYLHSEKKIHRDIKAANVLLLADFGVA |
| Sequence structure: | EKIGKGSFGEVFKVAIKIIDIQQEITVLSQCDPYVTKYYGSWIIMEYLGGGSALDLLEPYLHSEKKIHRDIKAANVLLLADFGVA |
