PDB-code
| Kinase structure | |
| Kinase: | MAP2K7 |
| Family: | STE7 |
| Group: | STE |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2068 |
| PDB: | 5B2L |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2016-04-06 |
| PubMed: | 26987717 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 5B2L | |||||
| 5B2L | Alternative model: | B | Chain: | A | |
| Structural information | |
| DFG conformation: | out-like |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 62.2° (18.7Å) |
| G-rich loop rotation: | 63.5° |
| Quality Score: | 8 |
| Resolution: | 2.1 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I3 | Ligand No | Protein No | ||
| Pocket alignment | |
| Uniprot sequence: | GEMGSGTCGQVWKIAVKQMRILMDLDVVLKSHPYIVQCFGTFIAMELMGTCAEKLKKRMLKEKHGVIHRDVKPSNILLLCDFGIS |
| Sequence structure: | GEMGSGTCGQVWKIAVKQMRILMDLDVVLKSHPYIVQCFGTFIAMELMGTSAEKLKKRMLKEKHGVIHRDVKPSNILLLCDFGIS |
