PDB-code
| Kinase structure | |
| Kinase: | PRKACA (PKACa) |
| Family: | PKA |
| Group: | AGC |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1476 |
| PDB: | 5IZJ |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2016-07-20 |
| PubMed: | 27389935 |
| Chain: | B |
| (Alternate) Model: | A |
| More entries for 5IZJ | |||||
| 5IZJ | Alternative model: | A | Chain: | A | |
| 5IZJ | Alternative model: | B | Chain: | A | |
| 5IZJ | Alternative model: | B | Chain: | B | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 66.5° (20.3Å) |
| G-rich loop rotation: | 51.5° |
| Quality Score: | 8 |
| Resolution: | 1.85 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I1 I3 I4 I5 I9 | Ligand No No No No No | Protein Yes No Yes Yes No | ||
| Allosteric Ligand | |
| Allosteric ligand: | 6J9 |
 | |
| Pocket alignment | |
| Uniprot sequence: | KTLGTGSFGRVMLYAMKILHTLNEKRILQAVNPFLVKLEFSYMVMEYVPGGEMFSHLRRYLHSLDLIYRDLKPENLLIVTDFGFA |
| Sequence structure: | KTLGTGSFGRVMLYAMKILHTLNEKRILQAVNPFLVKLEFSYMVMEYVPGGEMFSHLRRYLHSLDLIYRDLKPENLLIVTDFGFA |
