PDB-code
| Kinase structure | |
| Kinase: | BRAF |
| Family: | RAF |
| Group: | TKL |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 1943 |
| PDB: | 5JSM |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2016-09-14 |
| PubMed: | 27571413 |
| Chain: | A |
| (Alternate) Model: | B |
| More entries for 5JSM | |||||
| 5JSM | Alternative model: | A | Chain: | A | |
| 5JSM | Alternative model: | A | Chain: | B | |
| 5JSM | Alternative model: | A | Chain: | C | |
| 5JSM | Alternative model: | A | Chain: | D | |
| 5JSM | Alternative model: | B | Chain: | B | |
| 5JSM | Alternative model: | B | Chain: | C | |
| 5JSM | Alternative model: | B | Chain: | D | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 45.4° (13.3Å) |
| G-rich loop rotation: | 63.2° |
| Quality Score: | 9.2 |
| Resolution: | 2.19 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 8 |
| Allosteric Ligand | |
| Allosteric ligand: | BEN |
 | |
| Pocket alignment | |
| Uniprot sequence: | QRIGSGSFGTVYKVAVKMLAFKNEVGVLRKTRVNILLFMGYAIVTQWCEGSSLYHHLHIYLHAKSIIHRDLKSNNIFLIGDFGLA |
| Sequence structure: | QRIGSGSFGTVYKVAVKMLAFKNEVGVLRKTRVNILLFMGYAIVTQWCEGSSLYHHLHAYLHAKSIIHRDLKSNNIFLIGDFGLA |
