PDB-code
| Kinase structure | |
| Kinase: | RIPK2 |
| Family: | RIPK |
| Group: | TKL |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2190 |
| PDB: | 5NG3 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2017-06-28 |
| PubMed: | 28545134 |
| Chain: | C |
| More entries for 5NG3 | |||
| 5NG3 | Chain: | A | |
| 5NG3 | Chain: | B | |
| 5NG3 | Chain: | D | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | out |
| G-rich loop angle (distance): | 47.8° (14.4Å) |
| G-rich loop rotation: | 45.8° |
| Quality Score: | 8 |
| Resolution: | 2.6 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I11 | Ligand No | Protein No | ||
| Pocket alignment | |
| Uniprot sequence: | RYLSRGASGTVSSVAVKHLDVLREAEILHKARSYILPILGIGIVTEYMPNGSLNELLHRHNMTPPLLHHDLKTQNILLIADFGLS |
| Sequence structure: | RYLSRGASGTVSSVAVRHLDVLREAEILHKARSYILPILGIGIVTEYMPNGSLNELLHRHNMTPPLLHHDLKTQNILLIADFGLS |
